FERRITE DS CORES
|
MODEL |
G.W |
SIZE(mm) |
|||||
|
A |
B |
C |
D |
E |
F |
||
|
DS30/19/13.3 |
35 |
30.5±0.5 |
9.5±0.2 |
20.3±0.3 |
25.9±0.5 |
13.3±0.2 |
6.6±0.2 |
|
DS30/18/12.4 |
34 |
30.0±0.4 |
8.9±0.2 |
20.3±0.3 |
24.2MIN |
12.4±0.2 |
6.0±0.2 |
|
DS33/19 |
45 |
33.2±0.5 |
9.4±0.15 |
23.7±0.3 |
26.6±0.4 |
13.5±0.2 |
6.5±0.15 |
|
DS33/24 |
52 |
33.2±0.5 |
12.05±0.15 |
23.7±0.3 |
26.6±0.4 |
13.5±0.2 |
9.25±0.15 |
|
DS34/19 |
45 |
34.2±0.5 |
9.4±0.15 |
23.7±0.3 |
26.8min |
13.5±0.2 |
6.5±0.15 |
|
DS40/27 |
82 |
39.8±0.5 |
13.5±0.2 |
28.3±0.35 |
33.2±0.5 |
16.0±0.25 |
9.9±0.2 |
|
DS40/28 |
83.6 |
39.8±0.5 |
14.0±0.2 |
28.3±0.35 |
33.2±0.5 |
16.0±0.25 |
10.4±0.2 |
|
MODEL |
PARAMETER |
AL±25%(nH/N^2) |
N.W(g) |
|||
|
C1mm-1 |
Lemm |
Aemm2 |
Vemm3 |
ZP40 |
||
|
DS30/19/13.3 |
0.43 |
49.9 |
117.0 |
5842.0 |
5350 |
30.8 |
|
DS30/18/12.4 |
0.36 |
46.2 |
126.7 |
5855.0 |
6500 |
28.0 |
|
DS33/19 |
0.35 |
51.4 |
147.4 |
7576.0 |
6000 |
39.6 |
|
DS33/24 |
0.42 |
61.9 |
147.4 |
9124.0 |
5200 |
45.8 |
|
DS34/19 |
0.35 |
51.5 |
147.3 |
7590.0 |
6200 |
39.0 |
|
DS40/27 |
0.34 |
71.3 |
205.0 |
14617.0 |
6000 |
72.2 |
|
DS40/28 |
0.36 |
73.3 |
205.0 |
15027.0 |
5900 |
73.6 |
